Hitachi ZX240H Hydraulic Excavator

Hitachi ZX240H Hydraulic Excavator Specs front
Hitachi ZX240H Hydraulic Excavator Specs front
Hitachi ZX240H Hydraulic Excavator Specs side
Hitachi ZX240H Hydraulic Excavator Specs side
Hitachi ZX240H Hydraulic Excavator Specs extended
Hitachi ZX240H Hydraulic Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 2

I

Max Cutting Height

31.6 ft in

J

Max Loading Height

22.18 ft in

K

Max Reach Along Ground

33.7 ft in

L

Max Vertical Wall Digging Depth

19.76 ft in

M

Max Digging Depth

22.81 ft in

Dimensions

B

Width to Outside of Tracks

9.81 ft in

D

Length of Track on Ground

11.36 ft in

E

Ground Clearance

1.51 ft in

G

Height to Top of Cab

9.91 ft in

H

Tail Swing Radius

9.65 ft in

Undercarriage

N

Shoe Size

23.63 in


Specifications

Engine

Number of Cylinders

6

Engine Make

2353

Engine Model

CC-6BG1T

Net Power

167 hp

Power Measured @

2100 rpm

Displacement

396.3 cu in

Max Torque

469.9 lb ft

Torque Measured @

1800 rpm

Aspiration

turbocharged

Operational

Operating Weight

40785.6 lb

Fuel Capacity

100.4 gal

Cooling System Fluid Capacity

6.1 gal

Hydraulic System Fluid Capacity

80.1 gal

Engine Oil Capacity

6.7 gal

Swing Drive Fluid Capacity

2.3 gal

Hydraulic System Relief Valve Pressure

4980 psi

Hydraulic Pump Flow Capacity

107.8 gal/min

Swing Mechanism

Swing Speed

12.6 rpm

Undercarriage

Number of Shoes per Side

51

Shoe Size

23.7 in

Number of Carrier Rollers per Side

2

Number of Track Rollers per Side

8

Ground Pressure

7.3 psi

Max Travel Speed

3.5 mph

Buckets

Reference Bucket Capacity

1.4 yd3

Minimum Bucket Capacity

1.1 yd3

Maximum Bucket Capacity

1.4 yd3

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

arm length 2960mm (9\'8\")

Max Digging Depth

22.9 ft in

Max Reach Along Ground

33.7 ft in

Max Cutting Height

31.6 ft in

Max Loading Height

22.2 ft in

Max Vertical Wall Digging Depth

19.8 ft in

Dimensions

Width to Outside of Tracks

9.9 ft in

Height to Top of Cab

10 ft in

Ground Clearance

1.6 ft in

Removal Counterweight Clearance

3.6 ft in

Tail Swing Radius

9.7 ft in

Length of Track on Ground

11.4 ft in
