Hitachi ZX200LC-3 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
31.52ft in
C
Shipping Height Of Unit
10.44ft in
I
Max Cutting Height
31.73ft in
J
Max Loading Height
22.41ft in
K
Max Reach Along Ground
30.35ft in
L
Max Vertical Wall Digging Depth
17.39ft in
M
Max Digging Depth
20.28ft in
Boom/Stick Option (Hex) 1
Arm Length 2.42m
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
31.24ft in
I
Max Cutting Height
32.94ft in
C
Shipping Height Of Unit
9.65ft in
J
Max Loading Height
23.56ft in
K
Max Reach Along Ground
31.99ft in
L
Max Vertical Wall Digging Depth
19.66ft in
M
Max Digging Depth
21.89ft in
Boom/Stick Option (Hex) 2
Arm Length 2.91m
Dimensions
E
Ground Clearance
1.48ft in
G
Height To Top Of Cab
9.68ft in
B
Width To Outside Of Tracks
9.81ft in
D
Length Of Track On Ground
12.01ft in
H
Tail Swing Radius
9.03ft in
Removal Counterweight Clearance
3.38ft in
Undercarriage
F
Track Gauge
7.85ft in
N
Shoe Size
23.63in
Ground Pressure
6.1psi
Number Of Shoes Per Side
49
Number Of Carrier Rollers Per Side
2
Max Travel Speed
3.42mph
Number Of Track Rollers Per Side
8
Specifications
Engine
Engine Make
2353
Engine Model
AI-4HK1X
Net Power
164hp
Power Measured @
2000rpm
Max Torque
483.2lb ft
Displacement
316.9cu in
Aspiration
Turbocharged , intercooler
Torque Measured @
1500rpm
Operational
Operating Weight
44974.4lb
Fuel Capacity
105.7gal
Cooling System Fluid Capacity
6.9gal
Hydraulic System Fluid Capacity
63.5gal
Engine Oil Capacity
6.1gal
Swing Drive Fluid Capacity
1.7gal
Hydraulic System Relief Valve Pressure
4974.8psi
Hydraulic Pump Flow Capacity
112.1gal/min
Swing Mechanism
Swing Speed
13.3rpm
Buckets
Reference Bucket Capacity
1.2yd3
Minimum Bucket Capacity
0.7yd3
Maximum Bucket Capacity
1.6yd3
