Hitachi EX60-5 Midi Excavator

Midi Excavator
Midi Excavator
Midi Excavator
Midi Excavator
Midi Excavator
Midi Excavator
MODEL.UNITS

Dimensions

Boom/Stick Option (Hex) 1

A

Shipping Length Of Unit

19.95ft in

C

Shipping Height Of Unit

8.44ft in

I

Max Cutting Height

23.46ft in

J

Max Loading Height

16.64ft in

K

Max Reach Along Ground

20.21ft in

L

Max Vertical Wall Digging Depth

11.55ft in

M

Max Digging Depth

13.62ft in

Boom/Stick Option (Hex) 1

Boom 3720mm (12\' 2\'\') / Stick 1620mm (5\' 4\'\')

Boom/Stick Option (Hex) 2

A

Shipping Length Of Unit

20.08ft in

C

Shipping Height Of Unit

9.45ft in

I

Max Cutting Height

24.78ft in

J

Max Loading Height

17.95ft in

K

Max Reach Along Ground

21.86ft in

M

Max Digging Depth

15.29ft in

L

Max Vertical Wall Digging Depth

13.33ft in

Boom/Stick Option (Hex) 2

Boom 3720mm (12\' 2\'\') / Stick 2120mm (6\' 11\'\')

Dimensions

B

Width To Outside Of Tracks

7.22ft in

D

Length Of Track On Ground

7.03ft in

E

Ground Clearance

1.19ft in

G

Height To Top Of Cab

8.44ft in

H

Tail Swing Radius

5.75ft in

Removal Counterweight Clearance

2.5ft in

Undercarriage

N

Shoe Size

17.72in

F

Track Gauge

5.75ft in

Ground Pressure

4.27psi

Number Of Shoes Per Side

37

Max Travel Speed

2.99mph

Number Of Track Rollers Per Side

5

Number Of Carrier Rollers Per Side

1


Specifications

Engine

Engine Make

2311

Engine Model

A-BD30

Net Power

54hp

Power Measured @

2200rpm

Displacement

180.3cu in

Max Torque

133.5lb ft

Torque Measured @

1500rpm

Aspiration

Natural

Operational

Operating Weight

13889.2lb

Fuel Capacity

9.5gal

Cooling System Fluid Capacity

2.7gal

Hydraulic System Fluid Capacity

23.8gal

Engine Oil Capacity

3.4gal

Swing Drive Fluid Capacity

0.5gal

Operational Voltage

12V

Alternator Supplied Amperage

25amps

Hydraulic System Relief Valve Pressure

4550psi

Hydraulic Pump Flow Capacity

41.9gal/min

Swing Mechanism

Swing Speed

14.5rpm

Buckets

Reference Bucket Capacity

0.4yd3

Minimum Bucket Capacity

0.2yd3

Maximum Bucket Capacity

0.5yd3
