Hitachi EH1100 Rock Truck
Units
Dimensions
Dimensions
A
Overall Length
30.52ft in
B
Overall Width
14.57ft in
C
Overall Height
15.16ft in
D
Wheelbase
14.08ft in
E
Ground Clearance
2.27ft in
F
Dump Height
29.14ft in
G
Dump Ground Clearance
2.5ft in
Dump
H
Dump Angle
60degrees
Load Capacity - Struck
35.97yd3
Load Capacity - Heaped
51.02yd3
Rated Payload
144000lb
Lower Time
14sec
Raise Time
11.1sec
Specifications
Engine
Number Of Cylinders
12
Engine Make
2350
Engine Model
12 V Series 2000
Net Power
725hp
Gross Power
760hp
Displacement
1458.5cu in
Aspiration
Turbocharged/Aftercooled
Operational
Fuel Capacity
185gal
Cooling System Fluid Capacity
62.1gal
Engine Oil Capacity
19gal
Steering System Fluid Capacity
26gal
Brake/Hoist System Fluid Capacity
46gal
Operating Voltage
24V
Alternator Supplied Amperage
75amps
Tire Size
24.00R35 E4 Radial
Transmission
Transmission Type
Allison M6610, planetary type with integral lock up converter
Number Of Gears - Forward
6 forward
Number Of Gears - Reverse
2 reverse
Max Speed
38.1mph
Weights
Empty Weight
94415.2lb
Loaded Weight
239001lb
Weight Distribution Front - Empty
49%
Weight Distribution Rear - Empty
51%
Weight Distribution Front - Loaded
32%
Weight Distribution Rear - Loaded
68%
