Hitachi CS125 Static Smooth Drum Roller

Hitachi CS125 Static Smooth Drum Roller Specs front
Hitachi CS125 Static Smooth Drum Roller Specs front
Hitachi CS125 Static Smooth Drum Roller Specs side
Hitachi CS125 Static Smooth Drum Roller Specs side
Hitachi CS125 Static Smooth Drum Roller Specs back
Hitachi CS125 Static Smooth Drum Roller Specs back
Units

Dimensions

Dimensions

A

Overall Length

16.54 in

B

Overall Width

6.89 ft in

D

Wheelbase

11.16 ft in

E

Ground Clearance

1.12 ft in

F

Drum Diameter - Front

5.39 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2353

Engine Model

AA-4JG1T

Net Power

75 hp

Power Measured @

2150 rpm

Displacement

186.7 cu in

Operational

Fuel Capacity

31.8 gal

Spray Water Capacity

177 gal

Max Speed

10.3 mph

Weights

Operating Weight - standard

22134.5 lb

Operating Weight - max ballast

31063.2 lb

Max Static Linear Load - Drive Drum

254.8 lb/in

Max Static Linear Load - guide drum

256 lb/in

Dimensions

Wheelbase

11.2 ft in

Overall Length

16.6 in

Overall Width

6.9 ft in

Height with ROPS

10.4 ft in

Height with out ROPS

8.6 ft in

Ground Clearance

1.2 ft in

Drum Diameter - Front

5.4 ft in

Drum Diameter - Rear

5.4 ft in
