Hitachi AH500D Articulated Dump Truck
Units
Dimensions
Dimensions
A
Overall Length
35.5ft in
B
Overall Width
12.8ft in
C
Overall Height
14.08ft in
D
Wheelbase
17.87ft in
E
Ground Clearance
1.75ft in
F
Dump Height
24.18ft in
G
Dump Ground Clearance
2.64ft in
Dump
H
Dump Angle
70degrees
Lower Time
9.9sec
Rated Payload
100089.88lb
Capacity - Struck
28yd3
Raise Time
11.2sec
Capacity - Heaped
36.89yd3
Specifications
Engine
Number Of Cylinders
8
Engine Make
2345
Engine Model
OM502LA
Gross Power
523hp
Net Power
512hp
Power Measured @
1800rpm
Max Torque
1583.6lb ft
Torque Measured @
1300rpm
Aspiration
Turbocharged & Intercooled
Displacement
972.2cu in
Operational
Fuel Capacity
169.1gal
Operating Voltage
24V
Alternator Supplied Amperage
100amps
Tire Size
875/65 R29
Transmission
Transmission Type
Allison HD4500R ORS Full automatic planetary transmission with integral retarder
Number Of Forward Gears
6
Number Of Reverse Gears
1
Max Speed
23.9mph
Weights
Front Axle - Empty
39462.8lb
Center Axle - Empty
20095.2%
Rear Axle - Empty
20007lb
Front Axle - Loaded
53859%
Center Axle - Loaded
62942%
Rear Axle - Loaded
62853.8lb
Total Empty
79564.9lb
Total Loaded
179654.8lb
