Hidromek HMK220LC-2 Hydraulic Excavator

Hidromek HMK220LC-2 Hydraulic Excavator Specs front
Hidromek HMK220LC-2 Hydraulic Excavator Specs front
Hidromek HMK220LC-2 Hydraulic Excavator Specs side
Hidromek HMK220LC-2 Hydraulic Excavator Specs side
Hidromek HMK220LC-2 Hydraulic Excavator Specs extended
Hidromek HMK220LC-2 Hydraulic Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

32.12 ft in

C

Shipping Height of Unit

10.14 ft in

I

Max Cutting Height

31.4 ft in

J

Max Loading Height

22.64 ft in

K

Max Reach Along Ground

32.42 ft in

L

Max Vertical Wall Digging Depth

16.74 ft in

M

Max Digging Depth

21.89 ft in

Dimensions

B

Width to Outside of Tracks

9.81 ft in

D

Length of Track on Ground

11.95 ft in

E

Ground Clearance

1.53 ft in

G

Height to Top of Cab

9.75 ft in

H

Tail Swing Radius

9.19 ft in

Undercarriage

F

Track Gauge

7.85 ft in

N

Shoe Size

23.63 in


Specifications

Engine

Number of Cylinders

6

Engine Make

2251

Engine Model

6D34-TLU2D

Gross Power

153 hp

Power Measured @

2000 rpm

Displacement

357.6 cu in

Max Torque

435.2 lb ft

Torque Measured @

1500 rpm

Aspiration

Turbocharger, intercooler

Operational

Operating Weight

49163.1 lb

Fuel Capacity

93.6 gal

Hydraulic System Fluid Capacity

121.6 gal

Engine Oil Capacity

4.8 gal

Swing Drive Fluid Capacity

1.4 gal

Operating Voltage

24 V

Alternator Supplied Amperage

50 amps

Hydraulic System Relief Valve Pressure

5120.5 psi

Hydraulic Pump Flow Capacity

118.4 gal/min

Swing Mechanism

Swing Speed

10.7 rpm

Undercarriage

Number of Shoes per Side

49

Shoe Size

23.7 in

Number of Carrier Rollers per Side

2

Number of Track Rollers per Side

9

Max Travel Speed

3.2 mph

Drawbar Pull

40785.1 lb

Track Gauge

7.9 ft in

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Boom 5800mm w/ Arm 2920mm

Shipping Height of Unit

10.2 ft in

Shipping Length of Unit

32.2 ft in

Max Digging Depth

21.9 ft in

Max Reach Along Ground

32.5 ft in

Max Cutting Height

31.4 ft in

Max Loading Height

22.7 ft in

Max Vertical Wall Digging Depth

16.8 ft in

Dimensions

Width to Outside of Tracks

9.9 ft in

Height to Top of Cab

9.8 ft in

Ground Clearance

1.6 ft in

Removal Counterweight Clearance

3.5 ft in

Tail Swing Radius

9.2 ft in

Length of Track on Ground

12 ft in
