Hesston 9240 Swather

Hesston 9240 Swather Specs front
Hesston 9240 Swather Specs front
Hesston 9240 Swather Specs side
Hesston 9240 Swather Specs side
Hesston 9240 Swather Specs back
Hesston 9240 Swather Specs back
Units

Dimensions

Dimensions

A

Length w/ Header

21.47 ft in

B

Overall Width

12.22 ft in

C

Height to Top of Cab

11.02 ft in

D

Wheelbase

11.67 in

E

Ground Clearance

39.77 in


Specifications

Engine

Engine Make

2347

Engine Model

Diesel 4.5QSBTII

Power

110 hp

Power Measured @

2500 rpm

Displacement

274 cu in

Aspiration

Turbocharged

Operational

Operating Weight w/o Attachment

8650 lb

Fuel Capacity

60 gal

Hydraulic System Fluid Capacity

23 gal

Engine Oil Capacity

2.1 gal

Front Tire Size

18.4 x 26, Turf Tread

Rear Tire Size

14L - 16.1

Operating Voltage

24 V

Alternator Supplied Amperage

95 amps

Transmission

Max Speed

15 mph

Final Drive Type

Planetary

Dimensions

Wheelbase

11.7 in

Length w/ Header

21.5 ft in

Overall Width

12.3 ft in

Height to Top of Cab

11.1 ft in

Ground Clearance

39.8 in

Front Wheel Tread Width

126.1 in

Rear Wheel Tread Width - min

84.5 in

Rear Wheel tread Width - max

120 in


Compare similar models

Manufacturer / Model

Power

Operating Weight w/o Attachment

Power

110 hp

Operating Weight w/o Attachment

8650 lb

Power

108 hp

Operating Weight w/o Attachment

8516 lb

Power

115 hp

Operating Weight w/o Attachment

8600 lb
