Haulotte Optimum 1930E Scissor Lift

Scissor Lift
Scissor Lift
Scissor Lift
Scissor Lift
Scissor Lift
Scissor Lift
Units

Dimensions

Dimensions

A

Overall Length

6.17 in

B

Overall Width

2.5 ft in

C

Height w/ Rails

6.5 ft in

D

Wheelbase

4.5 ft in

E

Ground Clearance

3 in

Platform

F

Max Platform Height

18.93 ft in

I

Deck Extension

36 in


Specifications

Engine

Engine Make

0

System Voltage

24 V

Battery Amp Hours

225

Operational

Operating Weight

3131 lb

Hydraulic System Fluid Capacity

5.3 gal

Max Speed

2.8 mph

Tire Size

12.5x4.25

Tire Fill/Type

Solid, non-marking

Platform

Max Working Height

25 ft in

Max Platform Height

19 ft in

Max Platform Weight Capacity

507 lb

Platform Inner Length

5.7 in

Platform Inner Width

2.3 in

Lift Time

23 sec

Lower Time

32 sec

Deck Extension

36 in

Dimensions

Wheelbase

4.5 ft in

Overall Length

6.2 in

Overall Width

2.5 ft in

Height w/ Rails

6.5 ft in

Height w/o Rails

2.9 ft in

Turning Radius

5.6 ft in

Ground Clearance

3 in
