Haulotte HS3388RTXL Scissor Lift
Units
Dimensions
Dimensions
A
Overall Length
17.5in
D
Wheelbase
9ft in
B
Overall Width
7.5ft in
C
Height W/ Rails
8.6ft in
E
Ground Clearance
14in
Height W/O Rails
5.58ft in
Turning Radius
16.3ft in
Platform
F
Max Platform Height
32.1ft in
I
Deck Extension
39in
Max Working Height
39.4ft in
Max Platform Weight Capacity
1544lb
Platform Inner Length
209in
Platform Inner Width
74in
Lower Time
65sec
Lift Time
43sec
Specifications
Engine
Gross Power
31.4hp
Fuel Type
Diesel
Operational
Operating Weight
12370lb
Fuel Capacity
17gal
Hydraulic System Fluid Capacity
26gal
Max Speed
3.7mph
Tire Size
10-16.5
Tire Fill/Type
Foam
