Haulotte Compact 12 RTE Scissor Lift
Units
Dimensions
Dimensions
A
Overall Length
8.7in
D
Wheelbase
6.14ft in
B
Overall Width
5.91ft in
C
Height W/ Rails
8.34ft in
E
Ground Clearance
9.85in
Height W/O Rails
4.6ft in
Turning Radius
12.41ft in
Platform
F
Max Platform Height
33.27ft in
I
Deck Extension
47.25in
Max Working Height
39.83ft in
Max Platform Weight Capacity
992.09lb
Platform Inner Length
98.43in
Platform Inner Width
60.63in
Lower Time
35sec
Lift Time
35sec
Specifications
Engine
System Voltage
48V
Number Of Batteries
8.0000
Battery Amp Hours
285.0000
Charger Amps
45amps
Operational
Operating Weight
8201.2lb
Hydraulic System Fluid Capacity
11.9gal
Max Speed
3.7mph
Tire Size
26x12-12
Tire Fill/Type
foam filled/non marking
