Haulmax 3900D Articulated Dump Truck
Units
Dimensions
Dimensions
A
Overall Length
47.96ft in
B
Overall Width
13.78ft in
C
Overall Height
14.22ft in
D
Wheelbase
25.79ft in
E
Ground Clearance
2.03ft in
F
Dump Height
31.34ft in
G
Dump Ground Clearance
2.21ft in
Dump
H
Dump Angle
55degrees
Lower Time
15sec
Capacity - Heaped
65yd3
Rated Payload
207234.52lb
Raise Time
16sec
Specifications
Engine
Number Of Cylinders
12
Engine Make
2236
Engine Model
C27 Acert
Gross Power
787hp
Net Power
740hp
Power Measured @
2000rpm
Displacement
1647.7cu in
Operational
Fuel Capacity
264.2gal
Hydraulic System Fluid Capacity
118.9gal
Cooling System Fluid Capacity
46.3gal
Engine Oil Capacity
25.1gal
Transmission Fluid Capacity
19.1gal
Tire Size
21.00xR35
Transmission
Number Of Forward Gears
7
Number Of Reverse Gears
1
Max Speed
46.8mph
Weights
Total Loaded
297624.1lb
