Hamm HD PLUS 90i VT Vibratory Smooth Drum Roller
Units
Dimensions
Dimensions
A
Overall Length
192.92in
B
Overall Width
5.91ft in
C
Height To Top Of Cab
9.88ft in
D
Wheelbase
145.67in
E
Ground Clearance
31.5in
Turning Radius - Inside
19.85ft in
Width Over Tyres
63.78in
Specifications
Engine
Emission Tier Level
EPA Tier 4
Number Of Cylinders
4
Engine Make
DEUTZ
Engine Model
TCD 3.6 L4
Gross Power
114hp
Net Power
114hp
Power Measured @
2300rpm
Operational
Def Tank Capacity
5.3gal
Operating Weight Cabin
19444.8lb
Operating Weight Rops
19070lb
Oscillating Angle
10degrees
Operating Weight
25088.7lb
Fuel Capacity
45.8gal
Water Spray Tank Fluid Capacity
220.4gal
Max Speed
4.1mph
Tires *If Applicable
11.00-20
Tires
4
Drum
Drum Thickness
0.7in
Tangential Amplitude , Rear - 1
0.1in
Drum Width
66.2in
Drum Diameter
47.3in
Static Linear Load
157.4lb/in
Vibration Frequency 1
42Hz
Nominal Amplitude - High
0.1in
Vibration Frequency 2
50Hz
Nominal Amplitude - Low
0.1in
Centrifugal Force - High
16860.7lb
Centrifugal Force - Low
13488.6lb
