Hamm 3625 HT Vibratory Smooth Drum Roller

Vibratory Smooth Drum Roller
Vibratory Smooth Drum Roller
Vibratory Smooth Drum Roller
Vibratory Smooth Drum Roller
Vibratory Smooth Drum Roller
Vibratory Smooth Drum Roller
Units

Dimensions

Dimensions

A

Overall Length

250.2in

C

Height To Top Of Cab

10.06ft in

D

Wheelbase

127.17in

E

Ground Clearance

16.74in

Angle Of Driving Slope-Front

32degrees

Width Over Cab

98.04in

Angle Of Driving Slope-Rear

27degrees

Loadover Height

7.75ft in

Turning Radius - Inside

16.21ft in


Specifications

Steering System

Steering Method

Articulated steering

Oscillating Angle

10degrees

Speeds

Size Of Tyres, Rear

EM 23.5-R25 XTLA

Engine

Emissions Certification

EU Stage IIIA / EPA Tier 3

Engine Power@Iso 14396

207.9hp

Engine Power@Saej1349

207.9hp

Number Of Cylinders

6

Engine Make

Deutz

Engine Model

TCD 2012 L04 2V

Power Measured @

2300rpm

Operational

Operating Weight Cabin

54641.6lb

Operating Weight Rops

54156.6lb

Fuel Capacity

76.7gal

Max Weight

55225.8lb

Max Speed

10mph

Axle Load - Front

35527.5lb

Axle Load - Rear

19114.1lb

Drum

Drum Type

smooth

Drum Thickness

1.8in

Drum Width

87.5in

Drum Diameter

63in

Static Linear Load

406.6lb/in

Vibration Frequency 1

25Hz

Nominal Amplitude - High

0.1in

Vibration Frequency 2

28Hz

Nominal Amplitude - Low

0.1in

Centrifugal Force - High

74411.8lb

Centrifugal Force - Low

54628.6lb
