Grove YB4409-2 Hydraulic Truck Crane
Units
Dimensions
Boom
I
Min Height @ Max Raise Angle
13.78ft in
J
Max Height @ Max Raise Angle - No Jib
32.81ft in
K
Min Working Radius
5ft in
L
Max Working Radius
31ft in
M
Max Elevating Angle
72degrees
Max Lift Capacity
18000lb
Swing Speed
2.05rpm
Number Of Sections
3
Dimensions
A
Transport Length
17.56ft in
B
Transport Width
6.44ft in
C
Transport Height
7.26ft in
E
Ground Clearance
0.83ft in
F
Width W/ Outriggers Extended
10.18ft in
G
Carrier Length
11.98ft in
H
Upper Structure Tail Swing Radius
4.34ft in
Specifications
Carrier Engine
Make
Grove
Model
QSB 3.3L turbo-charged
Gross Power
99hp
Power Measured @
2600rpm
Displacement
201.4cu in
Operational
Operating Weight
15800.6lb
Number Of Axels
2
Carrier Fuel Capacity
18.5gal
Upper Structure Hydraulic System Fluid Capacity
23.6gal
Operating Voltage
12V
Alternator Supplied Amperage
63amps
Tire Size
10.00x15 14PR
Transmission
Transmission Type
Clark synchromesh
Number Of Forward Gears
4
Number Of Reverse Gears
4
Max Speed - Forward
22.2mph
Max Speed - Reverse
22.2mph
