Grove TMS5000 Hydraulic Truck Crane
Units
Dimensions
Boom
I
Min Height @ Max Raise Angle
37.1ft in
J
Max Height @ Max Raise Angle - No Jib
114.8ft in
K
Min Working Radius
9.85ft in
L
Max Working Radius
98.43ft in
M
Max Elevating Angle
80degrees
Swing Speed
2.1rpm
Number Of Sections
4
Dimensions
Overall Length
44.62ft in
Overall Width
111.03in
Overall Height
11.59ft in
Specifications
Carrier Engine
Make
Grove
Model
RD8
Gross Power
295.9hp
Power Measured @
2500rpm
Torque Measured @
1400rpm
Operational
Carrier Fuel Capacity
79.3gal
Upper Structure Hydraulic System Fluid Capacity
166.5gal
Operating Voltage
24V
Tire Size
Front - 12.00.20.PR
Transmission
Transmission Type
Synchromesh
Number Of Forward Gears
9
Number Of Reverse Gears
1
Max Speed - Forward
46mph
Hydraulic
Maximum Operating Pressure
2845psi
