Grove T40 AWD Boom Lift

Grove T40 AWD Boom Lift Specs side
Grove T40 AWD Boom Lift Specs side
Grove T40 AWD Boom Lift Specs back
Grove T40 AWD Boom Lift Specs back
Grove T40 AWD Boom Lift Specs extended
Grove T40 AWD Boom Lift Specs extended
Units

Dimensions

Dimensions

A

Overall Length

24.84 in

B

Overall Width

7.85 ft in

C

Overall Height - mast lowered

7.76 ft in

D

Wheelbase

8 ft in

E

Ground Clearance

10 in

Platform

F

Max Platform Height

39.38 ft in

G

Max Horizontal Reach

34.13 ft in


Specifications

Engine

Engine Make

2380

Engine Model

LRG4.25

Gross Power

60 hp

Operational

Operating Weight

13699.6 lb

Fuel Capacity

25.1 gal

Hydraulic System Fluid Capacity

24 gal

Max Speed

3.5 mph

Tire Size

12x16.5 Loader Lug

Tire Fill/Type

Pneumatic

Platform

Max Working Height

46 ft in

Max Platform Height

39.4 ft in

Max Horizontal Reach

34.2 ft in

Max Platform Weight Capacity

500.5 lb

Platform Inner Length

93.8 in

Platform Inner Width

35.9 in

Height of Rails

3.7 ft in

Dimensions

Wheelbase

8 ft in

Overall Length

24.9 in

Overall Width

7.9 ft in

Overall Height - mast lowered

7.8 ft in

Turning Radius

15 ft in

Ground Clearance

10 in
