Grove GMK6300B All Terrain Crane

Grove GMK6300B All Terrain Crane Specs front
Grove GMK6300B All Terrain Crane Specs front
Grove GMK6300B All Terrain Crane Specs side
Grove GMK6300B All Terrain Crane Specs side
Grove GMK6300B All Terrain Crane Specs extend
Grove GMK6300B All Terrain Crane Specs extend
Units

Dimensions

Boom

I

Min Height @ Max Raise Angle

51 ft in

J

Max Height @ Max Raise Angle - no jib

206.7 ft in

K

Min Working Radius

9 ft in

L

Max Working Radius

175 ft in

M

Max Elevating Angle

82 degrees

Dimensions

A

Transport Length

64.57 ft in

B

Transport Width

9.78 ft in

C

Transport Height

12.96 ft in

F

Width w/ Outriggers Extended

27.89 ft in

G

Carrier Length

50.43 ft in

H

Upper Structure Tail Swing Radius

20.82 ft in


Specifications

UPPER STRUCTURE ENGINE

Number of cylinders

6

Cooling System

Water cooled

Make

Grove

Model

OM906LA

Gross Power

254.8 hp

Power Measured @

1800 rpm

Max Torque

811.4 lb ft

Torque Measured @

1100 rpm

CARRIER ENGINE

Make

Grove

Model

OM502LA

Gross Power

563.3 hp

Power Measured @

1800 rpm

Max Torque

1991.5 lb ft

Torque Measured @

1080 rpm

Number of cylinders

8

Operational

Operating Weight

157648 lb

Number of Axels

6

Upper Structure Fuel Capacity

87.2 gal

Carrier Fuel Capacity

132.1 gal

Upper Structure Hydraulic System Fluid Capacity

322.3 gal

Operating Voltage

24 V

Alternator Supplied Amperage

80 amps

Tire Size

20.5R25

Transmission

Transmission Type

Allison automatic CLT 755

Number of Forward Gears

5

Number of Reverse Gears

1

Boom

Number of Sections

5

Min Height @ Max Raise Angle

51 ft in

Max Height @ Max Raise Angle - no jib

206.7 ft in

Max Elevating Angle

82 degrees

Max Lift Capacity

600000 lb

Min Working Radius

9 ft in

Max Working Radius

175 ft in

Swing Speed

1.6 rpm

Dimensions

Transport Length

64.6 ft in

Transport Width

9.8 ft in

Transport Height

13 ft in

Width w/ Outriggers Extended

27.9 ft in

Carrier Length

50.5 ft in

Upper Structure Tail Swing Radius

20.9 ft in
