Gradall 544D10-55 Telescopic Forklift

Gradall 544D10-55 Telescopic Forklift Specs front
Gradall 544D10-55 Telescopic Forklift Specs front
Gradall 544D10-55 Telescopic Forklift Specs side
Gradall 544D10-55 Telescopic Forklift Specs side
Gradall 544D10-55 Telescopic Forklift Specs extended
Gradall 544D10-55 Telescopic Forklift Specs extended
Units

Dimensions

Dimensions

A

Length to Fork Face

19.72 ft in

B

Width Over Tires

8.21 ft in

C

Overall Height

8.14 ft in

D

Wheelbase

11.23 ft in

E

Ground Clearance

20.79 ft in

Lift

F

Max Lift Height

55 ft in

G

Max Forward Reach

42 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2240

Engine Model

e 4045HF275

Gross Power

124.8 hp

Torque Measured @

2500 rpm

Displacement

274.7 cu in

Aspiration

turbocharged

Operational

Operating Weight

33570 lb

Fuel Capacity

38.1 gal

Hydraulic System Fluid Capacity

40 gal

Operating Voltage

12 V

Alternator Supplied Amperage

65 amps

Drawbar Pull

18400 lb

Tire Size

14.00x24-12PR

Transmission

Max Speed - forward

19 mph

Hydraulic

Pump Type

single-section gear pump

Relief Valve Pressure

6300 psi

Lift

Max Lift Capacity

10000 lb

Max Lift Height

55 ft in

Max Load at Max Height

5000 lb

Max Forward Reach

42 ft in

Max Load at Max Reach

2500 lb

Dimensions

Length to Fork Face

19.8 ft in

Width Over Tires

8.3 ft in

Overall Height

8.2 ft in

Wheelbase

11.3 ft in

Ground Clearance

20.8 ft in

Turning Radius Outside Tires

14.6 ft in
