Goldoni Star 85 Quadrifoglio High 4WD Tractor
Units
Dimensions
Dimensions
A
Overall Length
10.99in
B
Width Outside Frame
6.13ft in
C
Height To Top Of Cab
7.29ft in
D
Wheelbase
6.44in
E
Ground Clearance
14.81in
Tire Size
Front 280/70x18\", Rear 420/70x24
Specifications
Engine
Number Of Cylinders
4
Engine Make
0
Net Power
81.9hp
Power Measured @
2600rpm
Displacement
169.5cu in
Torque Rise
12%
Aspiration
Turbocharged
Operational
Fuel Capacity
15.9gal
Operating Weight
5511.6lb
Turning Radius
9.6ft in
Transmission
Transmission Type
40 speeds, a lever can be used to select the 8+8 transmission with synchronized reverse shuttle or the 16+8 transmission with synchronized Dual power
Max Speed
24.9mph
Hydraulic System
Pump Flow Capacity
9.3gal/min
Number Of Remote Control Valves
2
