Gleaner A65 Combine

Combine
Combine
Combine
Combine
Combine
Combine
Units

Dimensions

Dimensions

A

Overall Length

29.86 ft in

D

Wheelbase

12.18 ft in

E

Ground Clearance

1.35 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2398

Engine Model

84 CTA

Power

300 hp

Power Measured @

2100 rpm

Displacement

512.6 cu in

Operational

Operating Weight w/o Attachment

28000 lb

Fuel Capacity

159.9 gal

Transmission Type

4 speed hydrostatic

Feeding

Conveyor Width

44.2 in

Threshing

Rotor Diameter

27.6 in

Rotor Length

140 in

Rotor Speed - Low

157 rpm

Rotor Speed - High

980 rpm

Concave Area

2201.1 in2

Separating

Separator Type

rotary

Separating Area

2232.1 in2

Cleaning System

Total Cleaning Area

6758.1 in2

Cleaning Fan Speed - Low

590 rpm

Cleaning Fan Speed - High

1350 rpm

Dimensions

Height to Top of Isomount Cab

12 ft in

Overall Length

29.9 ft in

Wheelbase

12.2 ft in

Ground Clearance

1.4 ft in

Grain Handling

Grain Tank Capacity

300 bu

Unloading Auger Length

23.8 ft in

Unloading Speed

2.5 bu/sec

Unloading Discharge Height

14.4 ft in
