Genie SX-135 XC Boom Lift
Units
Dimensions
Dimensions
A
Overall Length
777.96in
B
Overall Width
12.93ft in
D
Wheelbase
13.6ft in
E
Ground Clearance
15in
Gradeability
35%
Overall Height
10.01ft in
Weight - 4wd
47500.8lb
Platform
Platform Rotation
160degrees
Platform Inner Length
35.83in
Platform Inner Width
96.07in
Specifications
Engine
Power
Deutz TD2.9 L4, 74 hp (55 kW)
Emission Tier Level
Tier 4 final
Engine Model
SX-135 XC
Capacities
Auxiliary Power Unit
12 V DC
Fuel Tank
40gal
Hydraulic Tank
60gal
Lift Capacities
660lb
Operational
Turning Radius - Axle Outside
32.7ft in
Controls
12 V DC proportional
Turning Radius - Axle Inside
26.4ft in
Drive Speed - Stowed
2.7mph
Horizontal Reach - Maximum
80ft in
Below Ground Reach
8.9ft in
Working Height - Maximum
131.6ft in
Platform Height - Maximum
125ft in
Tires
445D50/710HD
