Genie GS2032 Scissor Lift

Genie GS2032 Scissor Lift Specs side
Genie GS2032 Scissor Lift Specs side
Genie GS2032 Scissor Lift Specs back
Genie GS2032 Scissor Lift Specs back
Genie GS2032 Scissor Lift Specs extended
Genie GS2032 Scissor Lift Specs extended
Units

Dimensions

Dimensions

A

Overall Length

8.01 in

B

Overall Width

2.66 ft in

C

Height w/ Rails

6.67 ft in

D

Wheelbase

6.07 ft in

E

Ground Clearance

3.55 in

Platform

F

Max Platform Height

20.02 ft in

I

Deck Extension

35.83 in


Specifications

Engine

System Voltage

24 V

Number of Batteries

4

Operational

Operating Weight

3573.7 lb

Hydraulic System Fluid Capacity

3.8 gal

Max Speed

2.2 mph

Tire Size

15x5x11

Tire Fill/Type

Solid non-marking

Platform

Max Working Height

26.6 ft in

Max Platform Height

20.1 ft in

Max Platform Weight Capacity

800.3 lb

Platform Inner Length

89 in

Platform Inner Width

31.9 in

Lift Time

30 sec

Lower Time

34 sec

Deck Extension

35.9 in

Dimensions

Wheelbase

6.1 ft in

Overall Length

8.1 in

Overall Width

2.7 ft in

Height w/ Rails

6.7 ft in

Height w/o Rails

5.8 ft in

Turning Radius

7 ft in

Ground Clearance

3.6 in


Compare similar models

Manufacturer / Model

Operating Weight

Max Working Height

Max Platform Weight Capacity

Operating Weight

3649 lb

Max Working Height

26.4 ft in

Max Platform Weight Capacity

770 lb

Operating Weight

3829.5 lb

Max Working Height

26.6 ft in

Max Platform Weight Capacity

800.3 lb

Operating Weight

3747.9 lb

Max Working Height

26.6 ft in

Max Platform Weight Capacity

749.6 lb
