Gehl 753Z Midi Excavator

Gehl 753Z Midi Excavator Specs front
Gehl 753Z Midi Excavator Specs front
Gehl 753Z Midi Excavator Specs side
Gehl 753Z Midi Excavator Specs side
Gehl 753Z Midi Excavator Specs extended
Gehl 753Z Midi Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

21.26 ft in

I

Max Cutting Height

21.76 ft in

J

Max Loading Height

14.77 ft in

K

Max Reach Along Ground

23.2 ft in

L

Max Vertical Wall Digging Depth

11.16 ft in

M

Max Digging Depth

13.23 ft in

Boom/Stick Option (HEX) 2

I

Max Cutting Height

22.38 ft in

J

Max Loading Height

15.39 ft in

K

Max Reach Along Ground

24.12 ft in

L

Max Vertical Wall Digging Depth

12.14 ft in

M

Max Digging Depth

14.18 ft in

Dimensions

D

Length of Track on Ground

7.44 ft in

E

Ground Clearance

1.12 ft in

G

Height to Top of Cab

8.75 ft in

H

Tail Swing Radius

3.78 ft in

Undercarriage

N

Shoe Size

17.72 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2291

Engine Model

Yanmar 4TNV98-VNS, A TIER II

Gross Power

69 hp

Net Power

57 hp

Power Measured @

2100 rpm

Displacement

202 cu in

Operational

Operating Weight

16975 lb

Fuel Capacity

24.6 gal

Hydraulic System Fluid Capacity

26.2 gal

Operating Voltage

12 V

Alternator Supplied Amperage

88 amps

Hydraulic System Relief Valve Pressure

3771 psi

Hydraulic Pump Flow Capacity

55.4 gal/min

Swing Mechanism

Swing Speed

8.7 rpm

Undercarriage

Shoe Size

17.8 in

Number of Track Rollers per Side

5

Ground Pressure

5 psi

Max Travel Speed

3.1 mph

Buckets

Reference Bucket Capacity

0.3 yd3

Minimum Bucket Capacity

0.2 yd3

Maximum Bucket Capacity

0.5 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Standard arm 5'7" (1700mm)

Shipping Length of Unit

21.3 ft in

Max Digging Depth

13.3 ft in

Max Reach Along Ground

23.2 ft in

Max Cutting Height

21.8 ft in

Max Loading Height

14.8 ft in

Max Vertical Wall Digging Depth

11.2 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Long arm 6'7" (2000mm)

Max Digging Depth

14.2 ft in

Max Reach Along Ground

24.2 ft in

Max Cutting Height

22.4 ft in

Max Loading Height

15.4 ft in

Max Vertical Wall Digging Depth

12.2 ft in

Dimensions

Height to Top of Cab

8.8 ft in

Ground Clearance

1.2 ft in

Tail Swing Radius

3.8 ft in

Length of Track on Ground

7.5 ft in
