Gehl 283Z Mini Excavator

Gehl 283Z Mini Excavator Specs front
Gehl 283Z Mini Excavator Specs front
Gehl 283Z Mini Excavator Specs side
Gehl 283Z Mini Excavator Specs side
Gehl 283Z Mini Excavator Specs extended
Gehl 283Z Mini Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

I

Max Cutting Height

14.11 ft in

J

Max Loading Height

9.76 ft in

K

Max Reach Along Ground

15.36 ft in

L

Max Vertical Wall Digging Depth

7.07 ft in

M

Max Digging Depth

9 ft in

Dimensions

D

Length of Track on Ground

8.67 ft in

E

Ground Clearance

0.91 ft in

G

Height to Top of Cab

7.92 ft in

H

Tail Swing Radius

2.5 ft in

Undercarriage

N

Shoe Size

11.82 in


Specifications

Engine

Engine Make

2348

Engine Model

3TNV76

Net Power

20.4 hp

Displacement

68 cu in

Operational

Operating Weight

5886 lb

Fuel Capacity

9.6 gal

Hydraulic System Fluid Capacity

7.1 gal

Hydraulic System Relief Valve Pressure

3263 psi

Hydraulic Pump Flow Capacity

23.8 gal/min

Swing Mechanism

Swing Speed

10.3 rpm

Undercarriage

Shoe Size

11.9 in

Number of Carrier Rollers per Side

1

Number of Track Rollers per Side

3

Ground Pressure

3.8 psi

Max Travel Speed

2.5 mph

Drawbar Pull

5732 lb

Boom/Stick Option (HEX) 1

Max Digging Depth

9 ft in

Max Reach Along Ground

15.4 ft in

Max Cutting Height

14.2 ft in

Max Loading Height

9.8 ft in

Max Vertical Wall Digging Depth

7.1 ft in

Dimensions

Height to Top of Cab

8 ft in

Ground Clearance

1 ft in

Tail Swing Radius

2.5 ft in

Length of Track on Ground

8.7 ft in


Compare similar models

Manufacturer / Model

Net Power

Operating Weight

Net Power

20 hp

Operating Weight

5886 lb

Net Power

20.7 hp

Operating Weight

5625 lb

Net Power

21.3 hp

Operating Weight

5976 lb
