Galion 150A Rough Terrain Crane
Units
Dimensions
Boom
I
Min Height @ Max Raise Angle
20ft in
J
Max Height @ Max Raise Angle - No Jib
60ft in
K
Min Operating Radius
10ft in
M
Max Elevating Angle
70degrees
L
Max Operating Radius
60ft in
Swing Speed
4.41rpm
Max Lift Capacity
30000.51lb
Number Of Sections
4
Dimensions
A
Transport Length
29.51ft in
B
Transport Width
6.5ft in
C
Transport Height
11.09ft in
D
Wheelbase
108in
F
Width W/ Outriggers Extended
14.21ft in
G
Carrier/Base Length
16.88ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
Komatsu
Engine Model
S6D102E-1
Net Power
121hp
Power Measured @
2500rpm
Max Torque
368.1lb ft
Torque Measured @
1200rpm
Displacement
358.9cu in
Fuel Type
Diesel
Bore
4.1in
Stroke
4.8in
Aspiration
Turbocharged
Operational
Operating Weight
41843.8lb
Operating Voltage
12V
Alternator Supplied Amperage
62amps
Tire Size
14.00 x 24-16 PR
Transmission
Transmission Type
Powershift
Max Speed - Forward
26.5mph
Max Speed - Reverse
26.5mph
