Fiat-Hitachi FB110.2 Wheel Loader

Fiat-Hitachi FB110.2 Wheel Loader Specs front
Fiat-Hitachi FB110.2 Wheel Loader Specs front
Fiat-Hitachi FB110.2 Wheel Loader Specs side
Fiat-Hitachi FB110.2 Wheel Loader Specs side
Fiat-Hitachi FB110.2 Wheel Loader Specs back
Fiat-Hitachi FB110.2 Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

8.83 ft in

Dimensions

A

Length with Bucket on Ground

19.79 ft in

B

Width Over Tires

8.14 ft in

C

Height to Top of Cab

9.36 ft in

D

Wheelbase

7.22 ft in

F

Hinge Pin - Max Height

11.26 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2249

Engine Model

5.0 - 450T/PD

Net Power

106 hp

Gross Power

108 hp

Power Measured @

2070 rpm

Displacement

304 cu in

Torque Measured @

1400 rpm

Max Torque

326.1

Aspiration

Turbocharged

Operational

Operating Weight

18430.7 lb

Fuel Capacity

34.4 gal

Hydraulic System Fluid Capacity

36.2 gal

Engine Oil Fluid Capacity

4.3 gal

Cooling System Fluid Capacity

6.4 gal

Transmission Fluid Capacity

4.8 gal

Front Axle/Diff Fluid Capacity

4.5 gal

Rear Axle/Diff Fluid Capacity

2.4 gal

Turning Radius

17.1 ft in

Operating Voltage

12 V

Alternator Supplied Amperage

70 amps

Rear Axle Oscillation

16 degrees

Tire Size

16.9 x 24 (12PR)

Transmission

Transmission Type

Powershift

Number of Forward Gears

4

Number of Reverse Gears

2

Max Speed - Forward

24.3 mph

Max Speed - Reverse

8.6 mph

Hydraulic System

Pump Type

Load Sensing

Relief Valve Setting

30.5

Pump Flow Capacity

42.3 gal/min

Bucket

Breakout Force

1663586.1 lb

Dump Clearance at Max Raise

8.9 ft in

Bucket Width

7.8 ft in

Bucket Capacity - heaped

1.6 yd3

Dimensions

Length with Bucket on Ground

19.8 ft in

Width Over Tires

8.2 ft in

Height to Top of Cab

9.4 ft in

Wheelbase

7.3 ft in

Hinge Pin - Max Height

11.3 ft in
