Fiat-Hitachi EX165LC Hydraulic Excavator

Fiat-Hitachi EX165LC Hydraulic Excavator Specs front
Fiat-Hitachi EX165LC Hydraulic Excavator Specs front
Fiat-Hitachi EX165LC Hydraulic Excavator Specs side
Fiat-Hitachi EX165LC Hydraulic Excavator Specs side
Fiat-Hitachi EX165LC Hydraulic Excavator Specs extended
Fiat-Hitachi EX165LC Hydraulic Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

27.55 ft in

C

Shipping Height of Unit

9.7 ft in

I

Max Cutting Height

30.7 ft in

J

Max Loading Height

21.33 ft in

K

Max Reach Along Ground

26.09 ft in

L

Max Vertical Wall Digging Depth

15.93 ft in

M

Max Digging Depth

16.36 ft in

Dimensions

B

Width to Outside of Tracks

8.83 ft in

D

Length of Track on Ground

10.8 ft in

E

Ground Clearance

1.51 ft in

G

Height to Top of Cab

9.19 ft in

H

Tail Swing Radius

8.01 ft in

Undercarriage

F

Track Gauge

7.19 ft in

N

Shoe Size

19.69 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2353

Engine Model

A - 4BG 1 TPG

Gross Power

99.3 hp

Net Power

102 hp

Power Measured @

2300 rpm

Displacement

262.5 cu in

Aspiration

turbocharged

Operational

Operating Weight

37147.9 lb

Fuel Capacity

66.1 gal

Cooling System Fluid Capacity

4.9 gal

Hydraulic System Fluid Capacity

39.7 gal

Engine Oil Capacity

4.3 gal

Operating Voltage

24 V

Alternator Supplied Amperage

40 amps

Hydraulic System Relief Valve Pressure

4641.3 psi

Hydraulic Pump Flow Capacity

66.6 gal/min

Swing Mechanism

Swing Speed

13.2 rpm

Undercarriage

Shoe Size

19.7 in

Number of Carrier Rollers per Side

8

Number of Track Rollers per Side

2

Ground Pressure

6.9 psi

Max Travel Speed

3.3 mph

Track Gauge

7.2 ft in

Buckets

Reference Bucket Capacity

0.8 yd3

Minimum Bucket Capacity

0.4 yd3

Maximum Bucket Capacity

1.3 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

1800mm

Shipping Height of Unit

9.7 ft in

Shipping Length of Unit

27.6 ft in

Max Digging Depth

16.4 ft in

Max Reach Along Ground

26.1 ft in

Max Cutting Height

30.7 ft in

Max Loading Height

21.4 ft in

Max Vertical Wall Digging Depth

16 ft in

Dimensions

Width to Outside of Tracks

8.9 ft in

Height to Top of Cab

9.2 ft in

Ground Clearance

1.6 ft in

Removal Counterweight Clearance

3.1 ft in

Tail Swing Radius

8.1 ft in

Length of Track on Ground

10.8 ft in
