Fendt 720 4WD Tractor
Units
Dimensions
Dimensions
A
Overall Length
205.79in
D
Wheelbase
109.06in
E
Ground Clearance
21.74in
Overall Width
8.37ft in
Track Width Front
6.37ft in
Track Width Rear
6.3ft in
Turning Circle
18.05ft in
Overall Height
10.01ft in
Specifications
Electrical System
Starter
333 Amp
Battery
12 V, 180 Ah
Alternator
14 v,200 Amp
Engine
Starter
5.4hp
Engine Oil Service Interval Hours
500
Number Of Cylinders
6
Engine Model
720
Net Power
185hp
Gross Power
200hp
Pto Power
165hp
Power Measured @
1800rpm
Displacement
44cu in
Bore
4in
Stroke
5in
Aspiration
turbocharged, intercooler
Operational
Operating Weight
15399.3lb
Fuel Capacity
105.7gal
Operating Voltage
12V
Alternator Supplied Amperage
200amps
Power Take-Off(Pto)
Front Pto
540rpm
Rear Pto
1000
Transmission
Transmission Type
ML 180
Max Speed
31.1mph
Weights
Implement Weight
7010.7lb
Hydraulic System
Pump Flow Capacity
29.1gal/min
Relief Valve Pressure
2900.8psi
