Fendt 712 4WD Tractor

Fendt 712 4WD Tractor Specs front
Fendt 712 4WD Tractor Specs front
Fendt 712 4WD Tractor Specs side
Fendt 712 4WD Tractor Specs side
Fendt 712 4WD Tractor Specs back
Fendt 712 4WD Tractor Specs back
Units

Dimensions

Dimensions

A

Overall Length

15.32 in

B

Width Outside Frame

8.27 ft in

C

Height to Top of Cab

9.72 ft in

D

Wheelbase

8.86 in

E

Ground Clearance

21.74 in


Specifications

Engine

Number of Cylinders

6

Gross Power

128.8 hp

Net Power

114 hp

Power Measured @

2100 rpm

Torque Rise

38 %

Displacement

369.7 cu in

Aspiration

turbocharged, intercooler

Operational

Operating Weight

14561.6 lb

Fuel Capacity

89.9 gal

Alternator Supplied Amperage

200 amps

Operating Voltage

12 V

Transmission

Transmission Type

Stepless Vario transmission

Max Speed

31.1 mph

Hydraulic System

Pump Flow Capacity

29.1 gal/min

Relief Valve Pressure

2900.8 psi

Dimensions

Wheelbase

8.9 in

Overall Length

15.4 in

Height to Top of Cab

9.8 ft in

Ground Clearance

21.8 in

Width Outside Frame

8.3 ft in
