Fendt 209 VA 4WD Tractor
Units
Dimensions
Dimensions
A
Overall Length
11.65in
B
Width Outside Frame
3.79ft in
C
Height To Top Of Cab
7.74ft in
D
Wheelbase
6.99in
Specifications
Engine
Number Of Cylinders
4
Gross Power
92.6hp
Net Power
88.6hp
Power Measured @
2300rpm
Displacement
263.3cu in
Torque Rise
24%
Operational
Fuel Capacity
18.5gal
Operating Weight
5291.1lb
Alternator Supplied Amperage
55amps
Transmission
Transmission Type
Overdrive, fully synchronmesh, close-ratio
Number Of Forward Gears
20
Number Of Reverse Gears
6
Max Speed
21.8mph
Hydraulic System
Pump Flow Capacity
19.6gal/min
Relief Valve Pressure
2900.8psi
