EP CPQD15N Forklift

Forklift
Forklift
Forklift
Forklift
Forklift
Forklift
Units

Dimensions

Dimensions

A

Length to Fork Face

7.44ft in

B

Overall Width

3.55ft in

C

Overall Height - mast lowered

6.55ft in

D

Wheelbase

4.6ft in

E

Ground Clearance

4.53in

F

Height to Top of Overhead Guard

6.93ft in

G

Max Fork Height

13ft in

MAST

H

Mast Tip Forward

6degrees

I

Mast Tip Rear

12degrees


Specifications

Engine

Number of Cylinders

4

Engine Make

2311

Engine Model

K21

Power

41.6hp

Torque

112.2lb ft

Power Measured @

2600rpm

Displacement

126.1cu in

Torque Measured @

1600rpm

Fuel Type

Gasoline/ LPG

Operational

Operating Weight

6040.7lb

Tire Type

front 6.50-10-10PR rear 5.00-8-10PR

Max Speed

9.1mph

MAST

Load Capacity

3307lb

Load Center

19.7in

Mast Tip Forward

6degrees

Mast Tip Rear

12degrees

Lift Speed

98.5ft/min

Lower Speed

88.6ft/min

Dimensions

Wheelbase

4.6ft in

Length to Fork Face

7.5ft in

Overall Width

3.6ft in

Overall Height - mast lowered

6.6ft in

Max Fork Height

13ft in

Turning Radius

6.5ft in

Height to Top of Overhead Guard

7ft in

Ground Clearance

4.6in

Right Angle Stack

7.8ft in
