Dynapac CC900G Plus Vibratory Smooth Drum Roller
Units
Dimensions
Dimensions
A
Overall Length
83in
B
Overall Width
3.17ft in
C
Height To Top Of Cab
7.59ft in
D
Wheelbase
53in
E
Ground Clearance
10in
Gradeability
35%
Overhang Front
0.12ft in
Overhang Rear
0.12ft in
Turning Radius - Inside
6ft in
Turning Radius - Outside
9ft in
Curb Clearance
18in
Specifications
Engine
Engine Make
Honda
Engine Model
GX630R QYD
Gross Power
19hp
Power Measured @
3000rpm
Operational
Operating Weight Rops
2800lb
Oscillating Angle
13degrees
Operating Weight
2900lb
Fuel Capacity
6gal
Water Spray System Fluid Capacity
50gal
Max Speed
5mph
Steering Angle
34degrees
Drum
Drum Thickness
0.4in
Drum Width
35in
Drum Diameter
23in
Static Linear Load
34lb/in
Vibration Frequency 1
70Hz
Nominal Amplitude - High
0.1in
Centrifugal Force - High
3800lb
Brakes
Parking Brake
Failsafe brake in both drums
Service Brake
Hydrostatic in forward and reverse lever
