Dressta TD14M LT Crawler Tractor
Units
Dimensions
Dimensions
A
Length W/ Blade
18.18ft in
B
Width Over Tracks
8.01ft in
C
Height To Top Of Cab
10.63ft in
D
Length Of Track On Ground
10.41ft in
E
Ground Clearance
1.42ft in
F
Length W/O Blade
13.78ft in
Undercarriage
G
Track Gauge
6.17ft in
H
Standard Shoe Size
22.05in
Number Of Carrier Rollers Per Side
8
Ground Pressure
6.9psi
Ground Contact Area
5580in2
Number Of Shoes Per Side
46
Number Of Track Rollers Per Side
2
Specifications
Engine
Number Of Cylinders
6
Engine Make
2347
Engine Model
QSB6.7
Gross Power
173hp
Net Power
160hp
Power Measured @
1800rpm
Max Torque
659lb ft
Displacement
408cu in
Torque Measured @
1350rpm
Aspiration
Turbocharged
Operational
Operating Weight
37699.1lb
Fuel Capacity
100.4gal
Cooling System Fluid Capacity
9gal
Engine Oil Capacity
4.9gal
Hydraulic Fluid Capacity
15.6gal
Powertrain Fluid Capacity
33.1gal
Final Drives Fluid Capacity
7.4gal
Transmission
Transmission Type
Powershift
Number Of Forward Gears
3
Number Of Reverse Gears
3
Max Speed - Forward
6.8mph
Max Speed - Reverse
8.1mph
Hydraulic System
Relief Valve Pressure
2540psi
Pump Flow Capacity
30.2gal/min
Standard Blade
Width
10.7ft in
Height
47.3in
Capacity
4.2yd3
Cutting Depth
21.2in
