Dressta RD200C Motor Grader

Dressta RD200C Motor Grader Specs front
Dressta RD200C Motor Grader Specs front
Dressta RD200C Motor Grader Specs side
Dressta RD200C Motor Grader Specs side
Dressta RD200C Motor Grader Specs back
Dressta RD200C Motor Grader Specs back
Units

Dimensions

Dimensions

A

Overall Length

31.3 ft in

B

Width Over Tires

8.21 ft in

D

Wheelbase

23.96 ft in

G

Tandem Axle Wheelbase

5.06 ft in

H

Blade Base

10.01 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2347

Engine Model

QSB 6.7

Power Measured @

2400 rpm

Net Power Gear 5-6

178 hp

Torque Measured @

1500 rpm

Max Power

178 hp

Net Torque Gears 5-6

685.2 lb ft

Displacement

409 cu in

Aspiration

turbocharged and CAC

Operational

Std Operation Weight - Total

80195.4 lb

Fuel Capacity

100.4 gal

Cooling System Fluid Capacity

10.6 gal

Hydraulic System Fluid Capacity

34.4 gal

Transmission Fluid Capacity

9.3 gal

Rear Diff/Final Drive Fluid Capacity

2 gal

Tandem Case Fluid Capacity (each)

8 gal

Tire Size

14.00 - 24 G-2 16PR

Operating Voltage

24 V

Alternator Supplied Amperage

75 amps

Steering

Articulation Angle

25 degrees

Turning Radius

24606.3 ft in

Transmission

Transmission Type

powershift transmission

Number of Gears - Forward

6

Number of Gears - Reverse

3

Max Speed - Forward

27.8 mph

Max Speed - Reverse

19.6 mph

Front Axle

Wheel Lean

22 degrees

Oscillation - Total

40 degrees

Ground Clearance

1.9 ft in

Moldboard

Moldboard Width

12.1 ft in

Moldboard Height

26.4 in

Moldboard Thickness

0.9 in

Max Depth of Cut

13.8 in

Side Shift Left

31.5 in

Side Shift Right

31.5 in

Hydraulic System

Pump Type

axial piston pump

Pump Flow

21.2 gal/min

Relief Valve Pressure

2030.6 psi

Circle

Diameter

53.2 in

Rotation

360 degrees

Max Lift Above Ground

19.7 in

Dimensions

Height to Top of Isomount Cab

10.9 ft in

Overall Length

31.3 ft in

Width Over Tires

8.3 ft in

Wheelbase

24 ft in

Blade Base

10.1 ft in

Tandem Axle Wheelbase

5.1 ft in
