Doosan S300LL Log Loader
Units
Dimensions
Boom/Stick Option (Lgl) 1
A
Shipping Length
48.17ft in
C
Shipping Height
15.37ft in
Boom/Stick Option (Lgl) 1
Boom 20'8" (6300mm)/Stick 12'10" (3910mm)
Max Lift Capacity Over Front At Ground Level
28570lb
Dimensions
B
Overall Width
11.82ft in
D
Length Of Track On Ground
13.16ft in
E
Ground Clearance
2.54ft in
H
Tail Swing Radius
10.5ft in
Undercarriage
Max Speed
3.11mph
Shoe Size
27.56in
Specifications
Engine
Engine Make
2252
Engine Model
DE08TIS
Net Power
197hp
Power Measured @
1900rpm
Operational
Operating Weight
78600lb
Swing Mechanism
Swing Speed
10.1rpm
Hydraulic
Pump Type
axial piston pump
Pump Flow Capacity
130gal/min
Relief Valve Pressure
4690psi
