Doosan S255LCV Hydraulic Excavator

Doosan S255LCV Hydraulic Excavator Specs front
Doosan S255LCV Hydraulic Excavator Specs front
Doosan S255LCV Hydraulic Excavator Specs side
Doosan S255LCV Hydraulic Excavator Specs side
Doosan S255LCV Hydraulic Excavator Specs extended
Doosan S255LCV Hydraulic Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

I

Max Cutting Height

31.17 ft in

J

Max Loading Height

21.79 ft in

K

Max Reach Along Ground

33.01 ft in

L

Max Vertical Wall Digging Depth

19.95 ft in

M

Max Digging Depth

22.28 ft in

Boom/Stick Option (HEX) 2

I

Max Cutting Height

30.12 ft in

J

Max Loading Height

20.87 ft in

K

Max Reach Along Ground

31.37 ft in

L

Max Vertical Wall Digging Depth

17.59 ft in

M

Max Digging Depth

20.64 ft in

Boom/Stick Option (HEX) 3

I

Max Cutting Height

31.89 ft in

J

Max Loading Height

22.51 ft in

K

Max Reach Along Ground

34.59 ft in

L

Max Vertical Wall Digging Depth

21.53 ft in

M

Max Digging Depth

23.92 ft in

Dimensions

B

Width to Outside of Tracks

10.5 ft in

D

Length of Track on Ground

12.57 ft in

E

Ground Clearance

1.48 ft in

G

Height to Top of Cab

9.85 ft in

H

Tail Swing Radius

9.96 ft in

Undercarriage

F

Track Gauge

8.54 ft in

N

Shoe Size

23.63 in


Specifications

Engine

Number of Cylinders

6

Engine Make

2252

Engine Model

DB58TIS

Net Power

162 hp

Power Measured @

1950 rpm

Displacement

353 cu in

Max Torque

491.3 lb ft

Torque Measured @

1400 rpm

Aspiration

turbocharged air-to-air intercooled

Operational

Operating Weight

54200 lb

Fuel Capacity

97.8 gal

Cooling System Fluid Capacity

9.6 gal

Hydraulic System Fluid Capacity

76.7 gal

Engine Oil Capacity

5.1 gal

Swing Drive Fluid Capacity

3 gal

Operating Voltage

24 V

Hydraulic System Relief Valve Pressure

4690 psi

Hydraulic Pump Flow Capacity

118.4 gal/min

Swing Mechanism

Swing Speed

10.9 rpm

Undercarriage

Number of Shoes per Side

51

Shoe Size

23.7 in

Number of Carrier Rollers per Side

2

Number of Track Rollers per Side

10

Ground Pressure

7 psi

Max Travel Speed

3.2 mph

Track Gauge

8.6 ft in

Buckets

Reference Bucket Capacity

1.5 yd3

Minimum Bucket Capacity

0.7 yd3

Maximum Bucket Capacity

1.7 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Boom 19'4" (5900mm)/Stick 9'10" (3000mm)

Max Digging Depth

22.3 ft in

Max Reach Along Ground

33.1 ft in

Max Cutting Height

31.2 ft in

Max Loading Height

21.8 ft in

Max Vertical Wall Digging Depth

20 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Boom 19'4" (5900mm)/Stick 8'2" (2500mm)

Max Digging Depth

20.7 ft in

Max Reach Along Ground

31.4 ft in

Max Cutting Height

30.2 ft in

Max Loading Height

20.9 ft in

Max Vertical Wall Digging Depth

17.6 ft in

Boom/Stick Option (HEX) 3

Boom/Stick Option (HEX) 3

Boom 19'4" (5900mm)/Stick 11'6" (3500mm)

Max Digging Depth

24 ft in

Max Reach Along Ground

34.6 ft in

Max Cutting Height

31.9 ft in

Max Loading Height

22.6 ft in

Max Vertical Wall Digging Depth

21.6 ft in

Dimensions

Width to Outside of Tracks

10.5 ft in

Height to Top of Cab

9.9 ft in

Ground Clearance

1.5 ft in

Removal Counterweight Clearance

3.7 ft in

Tail Swing Radius

10 ft in

Length of Track on Ground

12.6 ft in
