Doosan DX55W Mobile Excavator
Units
Dimensions
Boom/Stick Option (Mex) 1
I
Max Cutting Height
19.62ft in
J
Max Loading Height
14ft in
M
Max Digging Depth
11.47ft in
Boom/Stick Option (Mex) 1
Boom 9'10" (3000mm)/Stick 5'3" (1600mm)
Boom/Stick Option (Mex) 2
I
Max Cutting Height
20.25ft in
J
Max Loading Height
14.62ft in
M
Max Digging Depth
12.46ft in
Boom/Stick Option (Mex) 2
Boom 9'10" (3000mm)/Stick 6'3" (1900mm)
Dimensions
D
Wheelbase
6.89ft in
B
Overall Width
6.3in
E
Ground Clearance
0.96ft in
G
Height To Top Of Cab
9.37ft in
N
Upper Structure Clearance
3.22ft in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2348
Engine Model
4TNV98-E
Net Power
54.7hp
Power Measured @
2400rpm
Displacement
202.5cu in
Torque Measured @
1550rpm
Net Torque
152lb ft
Operational
Fuel Capacity
31.8gal
Cooling System Fluid Capacity
2.7gal
Engine Oil Capacity
3.1gal
Hydraulic System Fluid Capacity
39.1gal
Operational Voltage
12V
Alternator Supplied Amperage
60amps
Hydraulic System Relief Valve Pressure
3263.2psi
Hydraulic Pump Type
2 variable tandem type pumps
Hydraulic Pump Flow Capacity
31.8gal/min
Oscillating Axle Angle
10degrees
Tire Size
12-16.5-12PR(OTR)
Swing Mechanism
Swing Speed
8.7rpm
Transmission
Transmission Type
hydrostatic mechanical shift
Number Of Forward Gears
2
Number Of Reverse Gears
2
Max Travel Speed
18.7mph
Buckets
Reference Bucket Capacity
0.3yd3
Minimum Bucket Capacity
0.1yd3
Maximum Bucket Capacity
0.3yd3
