Cukurova MEK15ET Forklift

Cukurova MEK15ET Forklift Specs front
Cukurova MEK15ET Forklift Specs front
Cukurova MEK15ET Forklift Specs side
Cukurova MEK15ET Forklift Specs side
Cukurova MEK15ET Forklift Specs back
Cukurova MEK15ET Forklift Specs back
Units

Dimensions

Dimensions

A

Length to Fork Face

6.36 ft in

B

Overall Width

3.42 ft in

C

Overall Height - mast lowered

7.16 ft in

D

Wheelbase

4.19 ft in

E

Ground Clearance

2.96 in

F

Height to Top of Overhead Guard

6.57 ft in

G

Max Fork Height

10.83 ft in

MAST

H

Mast Tip Forward

4 degrees

I

Mast Tip Rear

6 degrees


Specifications

Engine

Engine Make

0

Fuel Type

Battery 48V

Operational

Operating Weight

6173 lb

Tire Type

Pneumatic

Number of Front Wheels

2

Number of Rear Wheels

1

Max Speed

6.3 mph

MAST

Load Capacity

3307 lb

Load Center

19.7 in

Mast Tip Forward

4 degrees

Mast Tip Rear

6 degrees

Max Fork Spread

32.7 in

Lift Speed

49.3 ft/min

Lower Speed

78.8 ft/min

Dimensions

Wheelbase

4.2 ft in

Length to Fork Face

6.4 ft in

Overall Width

3.5 ft in

Overall Height - mast lowered

7.2 ft in

Max Fork Height

10.9 ft in

Turning Radius

5.2 ft in

Height to Top of Overhead Guard

6.6 ft in

Ground Clearance

3 in

Right Angle Stack

10.7 ft in
