Crown SC 4520-30 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
6.04ft in
B
Overall Width
3.36ft in
C
Overall Height - Mast Lowered
6.92ft in
D
Wheelbase
4.18ft in
E
Ground Clearance
3in
F
Height To Top Of Overhead Guard
6.55ft in
G
Max Fork Height
15.84ft in
Turning Radius
4.85ft in
Mast
H
Mast Tip Forward
5degrees
I
Mast Tip Rear
5degrees
Lift Speed
63ft/min
Max Fork Spread
33in
Lower Speed
90ft/min
Load Center
24in
Number Of Mast Sections
3
Load Capacity
3000lb
Specifications
Engine
Fuel Type
Electric 36V
Operational
Operating Weight
8224lb
Tire Type
Cushion
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
7.6mph
