Clark Michigan CST20 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
5.8ft in
B
Overall Width
3.19ft in
C
Overall Height - Mast Lowered
6.92ft in
D
Wheelbase
4.23ft in
E
Ground Clearance
1.97in
F
Height To Top Of Overhead Guard
3.07ft in
G
Max Fork Height
9.84ft in
Right Angle Stack
5.8ft in
Turning Radius
5.21ft in
Mast
H
Mast Tip Forward
2degrees
I
Mast Tip Rear
8degrees
Number Of Mast Sections
2
Lower Speed
13ft/min
Load Center
24in
Load Capacity
4000lb
Lift Speed
31ft/min
Specifications
Engine
Fuel Type
Electric 24V
Operational
Operating Weight
5900lb
Tire Type
Poly
Number Of Front Wheels
2
Number Of Rear Wheels
1
Max Speed
1.6mph
