Clark Michigan C20SCL Forklift

Clark Michigan C20SCL Forklift Specs front
Clark Michigan C20SCL Forklift Specs front
Clark Michigan C20SCL Forklift Specs side
Clark Michigan C20SCL Forklift Specs side
Clark Michigan C20SCL Forklift Specs back
Clark Michigan C20SCL Forklift Specs back
Units

Dimensions

Dimensions

A

Length to Fork Face

6.9 ft in

B

Overall Width

3.09 ft in

C

Overall Height - mast lowered

7.23 ft in

D

Wheelbase

4.01 ft in

E

Ground Clearance

3.23 in

F

Height to Top of Overhead Guard

6.76 ft in

G

Max Fork Height

13.36 ft in

MAST

H

Mast Tip Forward

8 degrees

I

Mast Tip Rear

8 degrees


Specifications

Engine

Number of Cylinders

4

Engine Make

2251

Engine Model

4G63

Power

39.5 hp

Torque

101 lb ft

Power Measured @

2100 rpm

Displacement

122 cu in

Torque Measured @

1800 rpm

Fuel Type

LPG

Operational

Operating Weight

6843.2 lb

Tire Type

Cushion

Number of Front Wheels

2

Number of Rear Wheels

2

Max Speed

10.6 mph

MAST

Load Capacity

4409.3 lb

Load Center

24 in

Number of Mast Sections

3

Mast Tip Forward

8 degrees

Mast Tip Rear

8 degrees

Max Fork Spread

33 in

Lift Speed

104 ft/min

Lower Speed

88 ft/min

Dimensions

Wheelbase

4.1 ft in

Length to Fork Face

6.9 ft in

Overall Width

3.1 ft in

Overall Height - mast lowered

7.3 ft in

Max Fork Height

13.4 ft in

Turning Radius

6.2 ft in

Height to Top of Overhead Guard

6.8 ft in

Ground Clearance

3.3 in

Right Angle Stack

7.4 ft in
