Claas Arion 610 C 4WD Tractor

Claas Arion 610 C 4WD Tractor Specs front
Claas Arion 610 C 4WD Tractor Specs front
Claas Arion 610 C 4WD Tractor Specs side
Claas Arion 610 C 4WD Tractor Specs side
Claas Arion 610 C 4WD Tractor Specs back
Claas Arion 610 C 4WD Tractor Specs back
Units

Dimensions

Dimensions

A

Overall Length

16.92 in

C

Height to Top of Cab

10.03 ft in

D

Wheelbase

9.26 in

E

Ground Clearance

20 in


Specifications

Engine

Number of Cylinders

6

Engine Make

2467

Engine Model

ECE R 24

Net Power

114 hp

Gross Power

123.4 hp

Power Measured @

2200 rpm

Displacement

414.3 cu in

Operational

Operating Weight

13898 lb

Fuel Capacity

74 gal

Transmission

Transmission Type

Powershift speeds 4

Number of Forward Gears

16

Number of Reverse Gears

16

Max Speed

24.9 mph

Hydraulic System

Pump Flow Capacity

15.9 gal/min

Relief Valve Pressure

2900.8 psi

Number of Remote Control Valves

4

Dimensions

Wheelbase

9.3 in

Overall Length

17 in

Height to Top of Cab

10.1 ft in

Ground Clearance

20 in

Tire Size

Front 13.6 R 28, Rear 16.9R38
