Challenger MT545B 2WD 2WD Tractor

Challenger MT545B 2WD 2WD Tractor Specs front
Challenger MT545B 2WD 2WD Tractor Specs front
Challenger MT545B 2WD 2WD Tractor Specs side
Challenger MT545B 2WD 2WD Tractor Specs side
Challenger MT545B 2WD 2WD Tractor Specs back
Challenger MT545B 2WD 2WD Tractor Specs back
Units

Dimensions

Dimensions

A

Overall Length

15.19 in

B

Overall Width

6.76 ft in

D

Wheelbase

9.28 ft in

E

Ground Clearance

15.44 in


Specifications

Engine

Number of Cylinders

6

Engine Make

2236

Engine Model

C6.6 ACERT

PTO Power

120 hp

Power Measured @

2200 rpm

Displacement

402.8

Aspiration

Turbocharged and Aftercooled

Operational

Operating Weight

11052 lb

Fuel Capacity

71.4 gal

Cooling System Fluid Capacity

6.8 gal

Hydraulic System Fluid Capacity

18.5 gal

3 Point Hitch Lift Capacity @ 24 inches

10915 lb

Operating Voltage

24 V

Alternator Supplied Amperage

120 amps

Transmission

Transmission Type

Auto Power

Max Speed

25 mph

Hydraulic System

Relief Valve Setting

2900

Pump Flow Capacity

29.1 gal/min

Number of Remote Control Valves

2

Dimensions

Wheelbase

9.3 ft in

Overall Length

15.2 in

Overall Width

6.8 ft in

Height with ROPS

9.4 ft in

Ground Clearance

15.5 in
