Challenger MT297B 4WD Tractor
Units
Dimensions
Dimensions
A
Overall Length
11.23in
B
Width Outside Frame
5.81ft in
C
Height To Top Of Cab
7.65ft in
D
Wheelbase
6.57in
E
Ground Clearance
15.75in
Tire Size
(F)9.5-16 6ply;(R)16.9-26 6ply
Specifications
Engine
Number Of Cylinders
4
Gross Power
59.1hp
Pto Power
46.4hp
Power Measured @
2600rpm
Displacement
180cu in
Aspiration
Natural
Operational
Fuel Capacity
13.2gal
Operating Weight
4078lb
3 Point Hitch Type
Cat.I/II
3 Point Hitch Lift Capacity @ 24 Inches
3307lb
Transmission
Transmission Type
Synchroshuttle
Number Of Forward Gears
12
Number Of Reverse Gears
12
Max Speed
17.7mph
Hydraulic System
Pump Flow Capacity
17.5gal/min
Relief Valve Pressure
2276psi
