Caterpillar TH63 Non-US Telescopic Forklift

Caterpillar TH63 Non-US Telescopic Forklift Specs front
Caterpillar TH63 Non-US Telescopic Forklift Specs front
Caterpillar TH63 Non-US Telescopic Forklift Specs side
Caterpillar TH63 Non-US Telescopic Forklift Specs side
Caterpillar TH63 Non-US Telescopic Forklift Specs extended
Caterpillar TH63 Non-US Telescopic Forklift Specs extended
Units

Dimensions

Dimensions

A

Length to Fork Face

18.77 ft in

B

Width Over Tires

8.04 ft in

C

Overall Height

8.04 ft in

D

Wheelbase

9.75 ft in

E

Ground Clearance

17.72 ft in

Lift

F

Max Lift Height

4.11 ft in

G

Max Forward Reach

26.58 ft in


Specifications

Engine

Engine Model

3054

Gross Power

109 hp

Net Power

81 hp

Displacement

244.1 cu in

Operational

Operating Weight

20414.9 lb

Fuel Capacity

31.8 gal

Hydraulic System Fluid Capacity

39.7 gal

Tire Size

Construct: 15.5x24 12PR Agricult: 15.5x80-24

Transmission

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed - forward

19.9 mph

Max Speed - reverse

13.7 mph

Lift

Max Lift Capacity

6613.9 lb

Max Lift Height

4.2 ft in

Max Load at Max Height

6613.9 lb

Max Forward Reach

26.6 ft in

Max Load at Max Reach

3141.6 lb

Dimensions

Length to Fork Face

18.8 ft in

Width Over Tires

8.1 ft in

Overall Height

8.1 ft in

Wheelbase

9.8 ft in

Ground Clearance

17.8 ft in

Turning Radius Outside Tires

12.5 ft in


Compare similar models

Manufacturer / Model

Operating Weight

Max Lift Capacity

Max Forward Reach

Operating Weight

20399.4 lb

Max Lift Capacity

6613.9 lb

Max Forward Reach

29.1 ft in

Operating Weight

21054.2 lb

Max Lift Capacity

6613.9 lb

Max Forward Reach

28.8 ft in

Operating Weight

19600 lb

Max Lift Capacity

6700 lb

Max Forward Reach

27.9 ft in
