Caterpillar P26500 Forklift

Caterpillar P26500 Forklift Specs front
Caterpillar P26500 Forklift Specs front
Caterpillar P26500 Forklift Specs side
Caterpillar P26500 Forklift Specs side
Caterpillar P26500 Forklift Specs back
Caterpillar P26500 Forklift Specs back
Units

Dimensions

Dimensions

A

Length to Fork Face

14.36 ft in

B

Overall Width

8.26 ft in

C

Overall Height - mast lowered

10.62 ft in

D

Wheelbase

9.19 ft in

E

Ground Clearance

8.67 in

F

Height to Top of Overhead Guard

9.57 ft in

G

Max Fork Height

11.09 ft in

MAST

H

Mast Tip Forward

15 degrees

I

Mast Tip Rear

12 degrees


Specifications

Engine

Number of Cylinders

6

Engine Make

2251

Engine Model

6M60-TL

Power

148 hp

Torque

450 lb ft

Power Measured @

2100 rpm

Displacement

460 cu in

Torque Measured @

1600 rpm

Fuel Type

diesel

Operational

Operating Weight

37412 lb

Tire Type

pneumatic

Number of Front Wheels

4

Number of Rear Wheels

2

Max Speed

18 mph

MAST

Load Capacity

26455.5 lb

Load Center

23.7 in

Mast Tip Forward

15 degrees

Mast Tip Rear

12 degrees

Max Fork Spread

79.8 in

Lift Speed

94 ft/min

Lower Speed

94 ft/min

Dimensions

Wheelbase

9.2 ft in

Length to Fork Face

14.4 ft in

Overall Width

8.3 ft in

Overall Height - mast lowered

10.7 ft in

Max Fork Height

11.1 ft in

Turning Radius

13.4 ft in

Height to Top of Overhead Guard

9.6 ft in

Ground Clearance

8.7 in
