Caterpillar M312 Mobile Excavator

Caterpillar M312 Mobile Excavator Specs front
Caterpillar M312 Mobile Excavator Specs front
Caterpillar M312 Mobile Excavator Specs side
Caterpillar M312 Mobile Excavator Specs side
Caterpillar M312 Mobile Excavator Specs extended
Caterpillar M312 Mobile Excavator Specs extended
Units

Dimensions

Boom/Stick Option (MEX) 1

I

Max Cutting Height

25.86 ft in

J

Max Loading Height

18.51 ft in

K

Max Reach Along Ground

25 ft in

L

Max Vertical Wall Dig Depth

7.85 ft in

M

Max Digging Depth

14.51 ft in

Boom/Stick Option (MEX) 2

I

Max Cutting Height

26.94 ft in

J

Max Loading Height

19.23 ft in

K

Max Reach Along Ground

26.28 ft in

L

Max Vertical Wall Dig Depth

12.31 ft in

M

Max Digging Depth

15.82 ft in

Boom/Stick Option (MEX) 3

I

Max Cutting Height

28.06 ft in

J

Max Loading Height

20.31 ft in

K

Max Reach Along Ground

28.19 ft in

L

Max Vertical Wall Dig Depth

13.23 ft in

M

Max Digging Depth

17.79 ft in

Boom/Stick Option (MEX) 4

I

Max Cutting Height

28.06 ft in

J

Max Loading Height

20.31 ft in

K

Max Reach Along Ground

28.19 ft in

L

Max Vertical Wall Dig Depth

14.11 ft in

M

Max Digging Depth

17.79 ft in

Dimensions

B

Overall Width

8.21 in

D

Wheelbase

8.21 ft in

E

Ground Clearance

1.24 ft in

F

Overall Width - Outriggers Down

12.59 ft in

G

Height to Top of Cab

10.08 ft in

N

Upper Structure Clearance

4.15 ft in


Specifications

Engine

Engine Model

3054TA

Gross Power

114 hp

Displacement

243.5 cu in

Operational

Fuel Capacity

60.8 gal

Hydraulic System Fluid Capacity

47.6 gal

Hydraulic System Relief Valve Pressure

4785 psi

Hydraulic Pump Flow Capacity

71.4 gal/min

Tire Size

dual 10-20 16PR

Transmission

Max Travel Speed

21 mph

Boom/Stick Option (MEX) 1

Boom/Stick Option (MEX) 1

boom w/ stick 1600mm

Max Digging Depth

14.6 ft in

Max Reach Along Ground

25 ft in

Max Cutting Height

25.9 ft in

Max Loading Height

18.6 ft in

Max Vertical Wall Dig Depth

7.9 ft in

Boom/Stick Option (MEX) 2

Boom/Stick Option (MEX) 2

boom w/ stick 2000mm

Max Digging Depth

15.9 ft in

Max Reach Along Ground

26.3 ft in

Max Cutting Height

27 ft in

Max Loading Height

19.3 ft in

Max Vertical Wall Dig Depth

12.4 ft in

Boom/Stick Option (MEX) 3

Boom/Stick Option (MEX) 3

boom w/ stick 2300mm

Max Digging Depth

17.8 ft in

Max Reach Along Ground

28.2 ft in

Max Cutting Height

28.1 ft in

Max Loading Height

20.4 ft in

Max Vertical Wall Dig Depth

13.3 ft in

Boom/Stick Option (MEX) 4

Boom/Stick Option (MEX) 4

boom w/ stick 2600mm

Max Digging Depth

17.8 ft in

Max Reach Along Ground

28.2 ft in

Max Cutting Height

28.1 ft in

Max Loading Height

20.4 ft in

Max Vertical Wall Dig Depth

14.2 ft in

Dimensions

Overall Width

8.3 in

Overall Width - Outriggers Down

12.6 ft in

Height to Top of Cab

10.1 ft in

Wheelbase

8.3 ft in

Ground Clearance

1.3 ft in

Upper Structure Clearance

4.2 ft in
