Caterpillar GP45K Forklift

Caterpillar GP45K Forklift Specs front
Caterpillar GP45K Forklift Specs front
Caterpillar GP45K Forklift Specs side
Caterpillar GP45K Forklift Specs side
Caterpillar GP45K Forklift Specs back
Caterpillar GP45K Forklift Specs back
Units

Dimensions

Dimensions

A

Length to Fork Face

10.42 ft in

B

Overall Width

4.79 ft in

C

Overall Height - mast lowered

7.88 ft in

D

Wheelbase

6.57 ft in

E

Ground Clearance

5.91 in

F

Height to Top of Overhead Guard

7.39 ft in

G

Max Fork Height

11 ft in

MAST

H

Mast Tip Forward

6 degrees

I

Mast Tip Rear

10 degrees


Specifications

Engine

Number of Cylinders

6

Engine Model

TB45

Power

97 hp

Torque

207 lb ft

Power Measured @

2450 rpm

Displacement

275 cu in

Torque Measured @

1200 rpm

Fuel Type

gas

Operational

Operating Weight

14396 lb

Tire Type

pneumatic

Number of Front Wheels

2

Number of Rear Wheels

2

Max Speed

12.1 mph

MAST

Load Capacity

9920.9 lb

Load Center

23.7 in

Mast Tip Forward

6 degrees

Mast Tip Rear

10 degrees

Max Fork Spread

46.7 in

Lift Speed

4.8 ft/min

Lower Speed

5.4 ft/min

Dimensions

Wheelbase

6.6 ft in

Length to Fork Face

10.5 ft in

Overall Width

4.8 ft in

Overall Height - mast lowered

7.9 ft in

Max Fork Height

11 ft in

Turning Radius

9.3 ft in

Height to Top of Overhead Guard

7.4 ft in

Ground Clearance

6 in
