Caterpillar D8T WH Crawler Tractor

Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Units

Dimensions

Blades

Su - Blade Width

12.9ft in

Blade Type

SU, U

Lgp Su-Blade Capacity With Trash Rack

27.6yd3

U-Blade Capacity With Trash Rack

32.4yd3

Su-Blade Capacity - With Trash Rack

26.1yd3

U-Blade Width

14ft in

Dimensions

A

Length W/ Blade

19.99ft in

B

Width Over Tracks

8.66ft in

C

Height To Top Of Cab

11.35ft in

D

Length Of Track On Ground

10.53ft in

E

Ground Clearance

2.03ft in

F

Length W/O Blade

15.22ft in

Overall Length - Basic Tractor

15.22ft in

Width - Over Trunnions

10ft in

Width - Without Blade

120in

Width - With Blade

155in

Overall Length - With Blade

240in

Width - Without Trunnions - Standard Shoe

8.66ft in

Height - Rops/Canopy

11.35ft in

Height - Stripped Top

8.76ft in

Dimensions - Lgp

G

Track Gauge

92in

Machine Height - Grouser Tip - Exhaust Stack

129.7in

Length - Basic Tractor - With Striker Bars With Two Counterweights*

206.4in

Width - Tractor - Over Trunnions

130.4in

Height - Top Of Roof-Mounted Precleaner

145.2in

Note

*With the following attachments add: SU Blade 1844 mm/72.6 in; U Blade 2241 mm/88.2 in; Drawbar 406 mm/16.0 in.

Height - Grouser

3.1in

Machine Height - Grouser Tip - Length Of Track On Ground

126.2in

Without Trunnions - Standard Shoe Width

130in

Machine Height - Grouser Tip - Erops (Top Of Railing)

140.4in

Length - Basic Tractor - Tag Link Trunnion To Tip - Rear Grouser*

183in

Machine Height - Grouser Tip - Ground Clearance

24.1in

Dimensions - Non-Suspended

G

Track Gauge

82in

Width - Tractor - Over Trunnions

120.4in

Note

*With the following attachments add: SU Blade 1844 mm/72.6 in; U Blade 2241 mm/88.2 in; Drawbar 406 mm/16.0 in.

Height - Grouser

3.1in

Height - Top Of Roof-Mounted Precleaner

145.2in

Length - Basic Tractor - Tag Link Trunnion To Tip - Rear Grouser*

183in

Length - Basic Tractor - With Striker Bars With Two Counterweights*

206.4in

Machine Height - Grouser Tip - Erops (Top Of Railing)

140.7in

Machine Height - Grouser Tip - Exhaust Stack

136.31in

Machine Height - Grouser Tip - Ground Clearance

23.8in

Machine Height - Grouser Tip - Length Of Track On Ground

128.31in

Without Trunnions - Standard Shoe Width

106in

Dimensions - Standard

G

Track Gauge

82in

Length - Basic Tractor - With Striker Bars With Two Counterweights*

206.4in

Length - Basic Tractor - Tag Link Trunnion To Tip - Rear Grouser*

183in

Height - Top Of Roof-Mounted Precleaner

145.2in

Height - Grouser

3.1in

Machine Height - Grouser Tip - Ground Clearance

24.1in

Without Trunnions - Standard Shoe Width

106in

Note

*With the following attachments add: SU Blade 1844 mm/72.6 in; U Blade 2241 mm/88.2 in; Drawbar 406 mm/16.0 in.

Machine Height - Grouser Tip - Length Of Track On Ground

126.2in

Machine Height - Grouser Tip - Erops (Top Of Railing)

140.4in

Width - Tractor - Over Trunnions

120.4in

Machine Height - Grouser Tip - Exhaust Stack

136.7in

Undercarriage

G

Track Gauge

6.84ft in

H

Standard Shoe Size

22in

Length - Track On Ground

10.53ft in

Track Gauge - Lgp

92in

Track On Ground - Lgp

126in

Track Rollers/Side

8

Track Rollers/Side - Lgp

8

Track Width

1.84ft in

Number Of Track Rollers Per Side

8

Width - Shoe - Lgp

38in

Ground Contact Area - Lgp

9610in2

Ground Contact Area

5549in2


Specifications

Engine

Number Of Cylinders

6

Engine Make

2236

Engine Model

C15 ACERT

Gross Power

347hp

Net Power

310hp

Power Measured @

2000rpm

Displacement

928cu in

Bore

5.4in

Stroke

6.8in

Emissions

Tier 4 Final/Stage IV/Korea Tier 4

Engine Model

Cat C15 ACERT

Flywheel Power

335hp

Note (1)

All non road Tier 4 Interim and Final, Stage IIIB and IV, and Korea Tier 4 diesel engines are required to use only Ultra Low Sulfur Diesel (ULSD) fuels containing 15 ppm EPA/10 ppm EU (mg/kg) sulfur or less. Biodiesel blends up to B20 (20% blend by volume) are acceptable when blended with 15 ppm EPA/10 ppm EU (mg/kg) sulfur or less ULSD. B20 should meet ASTM D7467 specification (biodiesel blend stock should meet Cat biodiesel spec, ASTM D6751 or EN 14214). Cat DEO-ULS or oils that meet the Cat ECF-3, API CJ-4, and ACEA E9 specification are required. Consult your OMM for further machine specific fuel recommendations.

Note (2)

Diesel Exhaust Fluid (DEF) used in Cat Selective Catalytic Reduction (SCR) systems must meet the requirements outlined in the International Organization for Standardization (ISO) standard 22241.

Note (3)

The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 2.5 kg of refrigerant which has a CO2 equivalent of 3.575 metric tonnes.

Rpm

1850rpm

Net Power - 1,900 Rpm - Iso 9249/Sae J1349

312hp

Net Power - 1,900 Rpm - Iso 9249/Sae J1349 (Din)

317hp

Net Power - Maximum - Iso 9249/Sae J1349 At 1,700 Rpm

335hp

Net Power - Maximum - Iso 9249/Sae J1349 Din At 1,700 Rpm

343hp

Operational

Operating Weight

85150lb

Fuel Capacity

170gal

Operating Voltage

24V

Alternator Supplied Amperage

100amps

Transmission

1 Forward

2.1mph

2 Forward

3.8mph

3 Forward

6.6mph

1 Reverse

2.8mph

2 Reverse

5mph

3 Reverse

8.8mph

1.0 Forward

2.1mph

2.0 Forward

3.8mph

3.0 Forward

6.6mph

1.0 Reverse

2.8mph

2.0 Reverse

5mph

3.0 Reverse

8.8mph

Weights

Operating Weight

86710lb

Standard Blade

Width

12.9ft in

Capacity

26.1yd3

Service Refill Capacities

Fuel Tank

170gal

Standards

Rops

SAE J1040 MAY94, ISO 3471:1994

Fops

SAE J/ISO 3349 APR98 Level II, ISO 3449:1992 Level II

Rippers

Each Additional Shank

732lb

Operating Weights

Lgp Waste Handler

91600lb

Standard Waste Handler

86710lb

Blades - Capacity (Sae J1265)

8 U Landfill

27.7yd3

8 Su Landfill

25.6yd3

8 Su Lgp Landfill

28.9yd3

Blades - Width - Over End Bits

8 Su Landfill

12.9ft in

8 U Landfill

13.9ft in

8 Su Lgp Landfill

14.9ft in

Shipping Weight

Lgp Waste Handler

77900lb

Standard Waste Handler

73400lb
